Features
- Microprocessor based ON/OFF Controller for better control
- Time delay for Compressor
- Meeting ASTM/IS/IP specifications
- Separate Refrigeration, Control and Monitor system for each compartment for independent operation
- Castor wheels for easy movement
Applications
- For measuring cloud and pour point of diesel fuel, jet fuel, finished lubricants, base oil, bright stock, distillate fuel, gas oil, biofuel and biodiesels, black oil, crude oil, engine coolant(antifreeze), PAO and synthetic lubricants, automatic transmission fluids, engine and gear oil.
|
SPECIFICATIONS
|
|
Temperature Range
|
Compartment 1
|
0°C
|
|
Compartment 2
|
-17°C
|
|
Compartment 3
|
-34°C
|
|
Compartment 4
|
-51°C
|
|
Display Resolution
|
0.1°C
|
|
Temperature Controller
|
Microprocessor based ON/OFF Controller with RTD Sensor(PT-100)
(Separate controller for each compartment)
|
|
Control Accuracy
|
±20C
|
|
Refrigeration System
(Separate system for each compartment)
|
Compressor
|
Hermetically Sealed Compressor
(Qty: 2 for below -40°C range)
|
|
Condenser
|
Fin & Tube type Air-Cooled Condenser
|
|
Refrigerant
|
Compartment 1
|
R134a CFC free
|
|
Compartment 2
|
R134a CFC free
|
|
Compartment 3
|
R404a CFC free
|
|
Compartment 4
|
R404a and R508b CFC free
|
|
Cabinet Material
|
Exterior
|
CRCA with Powder Coated
|
|
Interior
|
Duly polished 304 grade Stainless Steel
|
|
Top
|
Teflon / PVC / Stainless steel
|
|
Compartment size
|
Height
|
175mm
|
|
Diameter
|
200mm
|
|
Insulation
|
High Density Polyurethane Insulation (PUF)
|
|
Accommodation of test jars
|
4 jars per compartment
|
|
Castors
|
Friction free Heavy Duty Castor Wheels with Lock
|
|
Power Source
|
230V, 50Hz Single Phase
|
|
Accessories
|
Test Jars
|
|
IP-1C Thermometer
|
|
Silicon cork
|
|
Copper Jacket
|
|
Disc
|
|
O-Ring
|
|
Calibration
|
NABL certified
|
|
Optional
|
Duly polished 304 grade Stainless Steel exterior cabinet
|
|
1400rpm motor with stirrer for uniform Temperature
|
|
Custom built Compartment size and temperature
|
Due to constant upgradation, specifications & features are subject to change without notice.
